Universal Beam is a structural beam used for support in construction. Popular sizes include: 150 ub 18, 200 ub 18, 200 ub 22, 200 ub 25, 250 ub 26, 250 ub, 250 ub 37, 310 ub 32, 310 ub 40, 310 ub 46.   "Material to EN 10025-2:2004
Dimensions and properties to BS4-1:2005"   AVAILABLE IN S355JR & S355JO
Structural steel comes in various standard lengths and is used for a variety of construction settings including:
• Residential construction
• Non residential construction
• Transport and mining infrastructure
• Engineering construction

• Manufacturing

tion	Dimensions					Static Parameters
	Dimensions					Moment of Inertia		Elastic Section Modulus
	Depth	Width	Web Thickness	Sectional Area	Weight	- Ix -	- Iy -	- Wx -	- Wy -
	- h -	- w -	- s -	(cm2)	(kg/m)	(cm4)	(cm4)	(cm3)	(cm3)
	(mm)	(mm)	(mm)

UB 127 x 76 x 13	127	76	4	16.5	13	473	55.7	74.5	14.7

UB 152 x 89 x 16	152.4	88.7	4.5	20.3	16	834	89.6	109.5	20.2

UB 178 x 102 x 19	177.8	101.2	4.8	24.3	19	1356	137	152.5	27

UB 203 x 102 x 23	203.2	101.8	5.4	29.4	23.1	2105	163.9	207.2	32.2
UB 203 x 133 x 25	203.2	133.2	5.7	32	25.1	2340	307.6	230.3	46.2
UB 203 x 133 x 30	206.8	133.9	6.4	38.2	30	2896	384.7	280	57.5

UB 254 x 102 x 22	254	101.6	5.7	28	22	2841	119.3	223.7	23.5
UB 254 x 102 x 25	257.2	101.9	6	32	25.2	3415	148.7	265.5	29.2
UB 254 x 102 x 28	260.4	102.2	6.3	36.1	28.3	4005	178.5	307.6	34.9
UB 254 x 146 x 31	251.4	146.1	6	39.7	31.1	4413	447.5	351.1	61.3
UB 254 x 146 x 37	256	146.4	6.3	47.2	37	5537	570.6	432.6	78
UB 254 x 146 x 43	259.6	147.3	7.2	54.8	43	6544	677.4	504.1	92

UB 305 x 102 x 25	305.1	101.6	5.8	31.6	24.8	4455	122.9	292.1	24.2
UB 305 x 102 x 28	308.7	101.8	6	35.9	28.2	5366	155.4	347.6	30.5
UB 305 x 102 x 33	312.7	102.4	6.6	41.8	32.8	6501	194.1	415.8	37.9
UB 305 x 127 x 37	304.4	123.4	7.1	47.2	37	7171	336.2	471.1	54.5
UB 305 x 127 x 42	307.2	124.3	8	53.4	41.9	8196	388.8	533.6	62.6
UB 305 x 127 x 48	311	125.3	9	61.2	48.1	9575	461	615.7	73.6
UB 305 x 165 x 40	303.4	165	6	51.3	40.3	8503	764.4	560.5	92.6
UB 305 x 165 x 46	306.6	165.7	6.7	58.8	46.1	9899	895.7	645.7	108.1
UB 305 x 165 x 54	310.4	166.9	7.9	68.8	54	11700	1063	753.6	127.4

UB 356 x 127 x 33	349	125.4	6	42.1	33.1	8249	280.2	472.7	44.7
UB 356 x 127 x 39	353.4	126	6.6	49.8	39.1	10172	357.8	575.6	56.8
UB 356 x 171 x 45	351.4	171.1	7	57.3	45	12070	811.1	686.7	94.8
UB 356 x 171 x 51	355	171.5	7.4	64.9	51	14140	968.3	796.4	112.9
UB 356 x 171 x 57	358	172.2	8.1	72.6	57	16040	1108	896	128.7
UB 356 x 171 x 67	363.4	173.2	9.1	85.5	67.1	19460	1362	1071	157.3

UB 406 x 140 x 39	398	141.8	6.4	49.7	39	12508	409.8	628.6	57.8
UB 406 x 140 x 46	403.2	142.2	6.8	58.6	46	15685	538.1	778	75.6
UB 406 x 178 x 54	402.6	177.7	7.7	69	54.1	18720	1021	930	114.9
UB 406 x 178 x 60	406.4	177.9	7.9	76.5	60.1	21600	1203	1063	135.3
UB 406 x 178 x 67	409.4	178.8	8.8	85.5	67.1	24330	1365	1189	152.7
UB 406 x 178 x 74	412.8	179.5	9.5	94.5	74.2	27310	1545	1323	172.2

UB 457 x 152 x 52	449.8	152.4	7.6	66.6	52.3	21370	645	950	84.6
UB 457 x 152 x 60	454.6	152.9	8.1	76.2	59.8	25500	794.6	1122	103.9
UB 457 x 152 x 67	458	153.8	9	85.6	67.2	28930	912.6	1263	118.7
UB 457 x 152 x 74	462	154.4	9.6	94.5	74.2	32670	1047	1414	135.6
UB 457 x 152 x 82	465.8	155.3	10.5	104.5	82.1	36590	1185	1571	152.5
UB 457 x 191 x 67	453.4	189.9	8.5	85.5	67.1	29380	1452	1296	152.9
UB 457 x 191 x 74	457	190.4	9	94.6	74.3	33320	1671	1458	175.5
UB 457 x 191 x 82	460	191.3	9.9	104.5	82	37050	1871	1611	195.6
UB 457 x 191 x 89	463.4	191.9	10.5	113.8	89.3	41020	2089	1770	217.8
UB 457 x 191 x 98	467.2	192.8	11.4	125.3	98.3	45730	2347	1957	243.5

UB 533 x 210 x 82	528.3	208.8	9.6	104.7	82.2	47540	2007	1800	192.3
UB 533 x 210 x 92	533.1	209.3	10.1	117.4	92.1	55230	2389	2072	228.3
UB 533 x 210 x 101	536.7	210	10.8	128.7	101	61520	2692	2292	256.4
UB 533 x 210 x 109	539.5	210.8	11.6	138.9	109	66820	2943	2477	279.2
UB 533 x 210 x 122	544.5	211.9	12.7	155.4	122	76040	3388	2793	319.7

UB 610 x 229 x 101	602.6	227.6	10.5	128.9	101.2	45780	2915	2515	256.1
UB 610 x 229 x 113	607.6	228.2	11.1	143.9	113	87320	3434	2874	301
UB 610 x 229 x 125	612.2	229	11.9	159.3	125.1	98610	3932	3221	343.4
UB 610 x 229 x 140	617.2	230.2	13.1	178.2	139.9	111800	4505	3622	391.4
UB 610 x 305 x 149	612.4	304.8	11.8	190	149.1	125900	9308	4111	611
UB 610 x 305 x 179	620.2	307.1	14.1	228.1	179	153000	11408	4935	743
UB 610 x 305 x 238	635.8	311.4	18.4	303.3	238.1	209500	15837	6589	1017
